MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard
MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard
Couldn't load pickup availability
Share
96 in stock
SKU:
View full details![MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard](http://www.freerchobby.cc/cdn/shop/products/6374-003.jpg?v=1599554400&width=1445)
![MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard](http://www.freerchobby.cc/cdn/shop/products/6374-005.jpg?v=1599554400&width=1445)
![MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard](http://www.freerchobby.cc/cdn/shop/products/6374-004.jpg?v=1599554386&width=1445)
![MP 6374 170KV Sensored Version Brushless Motor for Electric Skateboard](http://www.freerchobby.cc/cdn/shop/products/6374-002.jpg?v=1599554393&width=1445)
Motor Date
-
Specifications:
Motor Power: 3200W
Motor KV: 170
Model Type: 6374
Motor Wind: 9
Idle current: 1.9A
Motor Resistance: 0.05Ohm
Max. current: 95A
Battery type: 4-10S
ESC: 100-120A
Torque: 8Nm
Diameter(mm): 63.4
Length(mm): 77
Total length (mm):102
Shaft(mm): 8mm with keyway
Weight: 900g
Multicolumn
![](http://www.freerchobby.cc/cdn/shop/files/3_5babe0fc-2584-421a-92bd-91cd93c4f850.jpg?v=1715307155&width=1500)
Factory environment
Free RC Hobby is a company founded in2012 China, specializing in thedesign and manufacturing of brushless DC
motors, ESCs, and propellers.
![](http://www.freerchobby.cc/cdn/shop/files/74ee7eba682db8499bf4e9ef5578ad73.jpg?v=1718174650&width=1500)
MP6374 Motor use
Mainly used in electric scooter
![](http://www.freerchobby.cc/cdn/shop/files/2_0596b9ed-bacf-418e-ad48-b6eca28a273a.jpg?v=1715311140&width=1500)
The scope of application of the company motor
It is widely used in hydrofoil surfboard, electric skateboard bicycle powered paraglider, multi-rotor UAV, fixed-wing robot, electric tool, etc.
![](http://www.freerchobby.cc/cdn/shop/files/d74ebcc9833ea13b8b90e80ff651b102.jpg?v=1715308264&width=1500)
Transportation channels
Have USP, FedEX , DHL, TNT, UP SIn different ways.
![](http://www.freerchobby.cc/cdn/shop/files/04_6eff0b12-ac73-46fd-bcd2-311ffb251954.jpg?v=1718174702&width=1500)
Company certificate display
We strive to satisfy your needs as they define them and achieve
their expectations while delivering value. This is accomplished by
implementing thehighest industry standards to coordinate and direct
