Model：UF160 v2
Battery Section：48~96S
Continuous Current：160A (under good cooling conditions)
Current limiting：160A
PWM Input Signal Voltage：3.3V/5V(compatible)
BEC：5V/200MA output
Compatible Signal Frequency：50-500Hz
Power Line：10AWG
Motor Line：10AWG
Weight(without lines)：1480g
Protection Grade：IPX4
Size(L*W*H)：232.0*121.0*68.8mm
Working Environmental Temperature：-20~65 ℃
Throttle Pulse Width：default 1050us-1940us, throttle adjustment is available.
Online Update：available
Voltage protection: available
Temperature Protection：available
Stall Protection：available
Motor temperature detection: available
Throttle Loss Protection：available
Error Signal Output: available
Speed Signal Output： available
Interphase short-circuit protection：available
Communication interface: CAN
Trouble Shooting
E
